The LECHUAN CM10-AP10S-M is a compact one-touch locking 2-pin metal right angle plug designed by leading circular connector manufacturers for reliable electrical connections in space-limited applications. Ideal for electronic connectors suppliers targeting secure, efficient interfacing solutions.
Precision Design for Compact Connectivity Challenges
This one-touch locking style 2-pin metal right angle plug is engineered for professionals requiring reliable electrical connections in restricted spaces. Developed by expert circular connector manufacturers, the LECHUAN CM10-AP10S-M connector facilitates rapid mating/unmating while maintaining firm engagement, essential for control panel integrators and system assemblers. Its small footprint supports applications needing high-density connector deployment without sacrificing connection integrity. This solution targets engineers and procurement teams seeking dependable aviation connector alternatives with enhanced installation flexibility.
Durability and Electrical Integrity in Harsh Conditions
Built using synthetic rubber front insulators and UL94V-0 rated plastic at the rear, combined with gold-plated copper alloy contacts, this aviation plug connector ensures electrical reliability and corrosion resistance. The zinc alloy shell with trivalent chromium coating and nickel-plated retaining rings provide mechanical strength and environmental protection. Rated at 200V AC and 3A current per contact, it withstands dielectric tests of up to 1500V AC, confirming insulation performance. These measurable specifications meet stringent safety and operational standards expected from electronic connectors suppliers serving high-demand industries.
Industry Versatility and Compliance Assurance
This standard circular connector model fits various industrial sectors, including automation controls, aerospace systems, and OEM manufacturing. Its compact one-touch locking mechanism enables quick connect/disconnect cycles, crucial for maintenance and prototyping workflows. LECHUAN’s adherence to international standards and quality management systems allows system integrators to confidently deploy these connectors in aviation and industrial automation. As a trustworthy solution from circular connector manufacturers, it ensures sustained operational performance and seamless integration across multiple electrical connectivity architectures.
|
Product Name
|
Circular Connectors CM10-AP10S-M
|
|
Electrical Characteristic
|
Rated Voltage：200V AC(r.m.s.)
|
|
|
Rated Current：3A／Contact
|
|
|
Dielectric Withstanding Voltage：
1500V AC(r.m.s.)／１minute. [2-Contact]
900V AC(r.m.s.)／１minute. [10-Contact]
|
|
|
Insulation Resistance：1000MΩ min. at 500V DC
|
|
Environment
|
Operating Temperature:-25℃ to +85℃
|
Product Advantages
Innovative Structural Design for Reliable Integration
The CM10-AP10S-M features a metal right angle plug with a precision one-touch locking system that enhances mechanical stability and simplifies installation in confined spaces. This structural design, endorsed by seasoned circular connector manufacturers, allows for modular system integration adaptable to diverse layouts. The use of high-quality copper alloy contacts with gold plating and corrosion-resistant zinc alloy shells aligns with the rigorous demands of electronic connectors suppliers aiming to deliver durable aviation connector products that comply with industry standards, ensuring consistent connectivity under vibration and thermal stress.
Superior Performance Enhancing Usability and Safety
Performance-wise, the connector’s rating at 200V AC and 3A per contact supports robust electrical transmission in demanding environments. Ease of use is guaranteed by the quick-release locking mechanism, minimizing assembly time and maintenance efforts. The connector’s operational temperature range from -25℃ to +85℃ further consolidates its reliability for extended service life. This combination of user-focused design and technical resilience delivers tangible value to system engineers sourcing standard circular connectors with verified dielectric and insulation performance, supporting efficient, safe, and precise electrical connections.
Use Scenarios
Application in Compact Industrial Control Panels
In industrial control environments characterized by limited installation spaces, precise and secure connections are critical. The LECHUAN CM10-AP10S-M aviation plug connector fulfills the need for reliable signal and power transmission in compact control panels. Its one-touch locking mechanism permits rapid assembly or replacement under tight conditions without compromising connection integrity. Compliance with high dielectric voltage and corrosion resistance requirements makes it suitable for hazardous or moisture-prone manufacturing floors. Integrating this connector into electronic systems ensures stable operation and simplifies maintenance workflows for industrial electrical engineers and procurement teams.
Role in Aerospace and Aviation Equipment Interfaces
The aviation sector demands connectors that combine ruggedness, compact form factors, and secure locking mechanisms. This standard circular connector meets the strict requirements for aerospace plug connectors used in avionics modules and cockpit equipment. Its gold-plated copper contacts provide optimal conductivity essential for critical signal fidelity. The connector’s corrosion-resistant zinc alloy shell conforms to environmental stressors encountered in aviation applications. By deploying this product, aviation engineers and electronic connectors suppliers deliver reliable, rapid-mate components compatible with complex aerospace control systems, ensuring consistent function and regulatory adherence throughout the operational lifespan.
