Functional Targeting for Legacy System Compatibility
The CA3100A 14S-7SB circular plug connector is engineered primarily for industrial engineers and procurement professionals requiring a direct, seamless replacement for ITT Cannon Amphenol CA3100 family connectors. This product serves organizations maintaining legacy equipment or designing new assemblies with proven compatibility needs. It’s supplied in bulk packaging, supporting large-scale manufacturing and maintenance operations demanding repeatable, reliable circular plug connector solutions. As a trusted offering from a reputable electronic connector company, this product targets users prioritizing precision-fit, maintenance efficiency, and minimized system redesign risks.
Technical Specifications Emphasizing Durability and Electrical Integrity
Constructed with a robust zinc alloy shell plated in nickel, the CA3100 supports long service life and superior corrosion resistance consistent with demanding operational environments. Copper alloy contacts with gold plating ensure excellent conductivity and low contact resistance. Rated at 3A and 200V AC, it provides an insulation resistance exceeding 1,000 MΩ at 500V DC, and withstands dielectric voltage up to 1,500V AC for one minute. Its bayonet coupling mechanism facilitates rapid, secure mating, critical for minimizing downtime during field servicing. Solder and crimp termination options accommodate wire sizes up to 20 AWG, underscoring flexibility compatible with mil dtl 5015 connectors standards.
Applications in Defense and Industrial Equipment Deployments
This circular plug connector is widely utilized across defense electronics and heavy industrial sectors requiring mil-dtl-5015 compliant components for ruggedized, dependable interconnects. It acts as a drop-in solution for system validation, prototyping, and field replacement in equipment reliant on mil dtl 5015 connectors, ensuring operational consistency and regulatory compliance. The connector’s design supports critical workflows where rapid mating/un-mating cycles are frequent, such as maintenance in aerospace, military communications, and industrial automation. This product supports supply chain streamlining by providing engineers and procurement teams with a tested, standard interface for complex electronic assemblies.
|
Product Name
|
Circular Spec Connector
|
|
Material
|
Socket Cover Insulator Plastic(UL94V-0)
|
|
Black Socket Insulator :Plastic(UL94V-0)/Black
|
|
|
Fixed Pin Copper :Alloy/Nickel Plating
|
|
|
Contact Copper :Alloy/Gold Plating
|
|
|
Coupling Ring: Zinc Alloy/Nickel Plating
|
|
|
O Ring(Mating Side) :Synthetic Rubber/Black
|
|
|
Plug Shell:Zinc Alloy/Nickel Plating
|
|
|
ELECTRICAL
|
Rated Current 3A Max.
|
|
Contact Rated Voltage 200V AC(r.m.s.)
|
|
|
Max. Dielectric Withstanding Voltage 1500V AC(r.m.s.) ／ 1 minute
900V AC(r.m.s.) |
|
|
Insulation Resistance 1,000M Ω Min. at 500V DC
|
|
|
Operating Temperature Range -25℃ to +85℃
|
|
|
Applicable Wire Receptacle, Cable Receptacle
・Soldering only, 20AWG max. Plug ・Crimp：16AWG-20AWG ・Soldering Use,：16AWG Max. Receptacle, Cable Receptacle ・Soldering Use,：20AWG Max Plug ・Crimp：20AWG-28AWG RoHS ・Soldering Use,：20AWG Max. |
Product Advantages
Structural and Design Excellence in Connector Engineering
The CA3100 zinc alloy circular plug connector features a modular bayonet coupling system adaptable to legacy ITT Cannon Amphenol form factors, easing integration in existing hardware platforms. Its nickel-plated zinc alloy shell offers robust mechanical protection against environmental stressors while maintaining dimensional stability. The precision-machined copper alloy gold-plated contacts enhance electrical continuity, mitigating signal loss common in harsh conditions. Verified compatibility with mil-dtl-5015 standards affirms its suitability for applications requiring strict adherence to military-grade connector specifications. As a product from an established circular connector manufacturer, it embodies optimized manufacturing processes, reliability, and industry-standard performance.
Enhanced Performance and Operational Reliability
Users benefit from the CA3100’s combination of electrical performance and ergonomic design, enabling swift and secure connections through its bayonet coupling, which reduces assembly time and potential contact damage. The connector’s resistance to corrosion and temperature variability (-25°C to +85°C) provides stable performance in diverse conditions. This electronic connector company’s product supports flexible termination with both solder and crimp methods, easing field installation and repair. The bulk packaging format aligns with procurement efficiency, meeting volume demands without compromising quality. Its specifications and construction deliver dependable operations, which is critical for industries adhering to mil-dtl-5015 quality frameworks.
Use Scenarios
Use in Legacy Military Communication Systems
In military communication and control systems, connectors ensuring strict compliance with mil dtl 5015 connectors are essential for maintaining secure and reliable data transmission. The CA3100 circular plug connector serves as a direct replacement in legacy devices, facilitating system upgrades or repairs without redesign efforts. Its corrosion-resistant zinc alloy body and gold-plated contacts assure consistent signal integrity under battlefield or harsh environmental conditions. The bayonet coupling expedites rapid deployment and maintenance cycles, minimizing operational downtime. Integration of this connector into established system architectures supports logistical compatibility and lifecycle management dictated by military standards.
Application in Industrial Automation and Equipment Maintenance
Industrial automation environments typically require connectors capable of enduring frequent mating cycles and exposure to contaminants. The CA3100 connector fulfills these demands by offering a rugged shell, secure bayonet coupling, and high dielectric withstand voltage. It fits into control panels, sensors, and power distribution modules where reliability and quick replacement reduce production disruptions. Supporting both solder and crimp terminations enhances on-site flexibility for maintenance teams managing varied wire gauges. As a product from a specialized electronic connector company, it aligns with industry expectations for durable mil-dtl-5015 compliant circular connectors, facilitating seamless workflow integration in automated manufacturing lines.
