Product Information
|
Pin Front Insulator： Synthetic Rubber/Black
|
|
|
Pin Rear Insulator ：Plastic(UL94V-0)/Black
|
|
|
Pin Contact ： Copper Alloy/Gold Plating
|
|
|
O Ring(Mounting Side) ：Synthetic Rubber/Black
|
|
Receptacle Shell Zinc Alloy/Trivalent Chromium Finish(Black） Retaining Ring Copper Alloy/Nickel Plating Ground Lug Copper
Alloy/Gold Plating |
|
|
Electrical Characteristic
|
Rated Voltage:200V AC(r.m.s.)
|
|
Rated Current:3A／Contact
|
|
|
Dielectric Withstanding Voltage:
1500V AC(r.m.s.)／１minute. [2-Contact]
900V AC(r.m.s.)／１minute. [10-Contact]
|
|
|
Insulation Resistance:1000MΩ min. at 500V DC
|
|
|
Environment
|
Operating Temperature:-25℃ to +85℃
|
