The LECHUAN C091 M16 5Pin circular socket receptacle is a robust, IP67-rated cable connector offering solder termination and front panel mounting. Designed by leading electrical connectors manufacturers for PCB applications.
Functional Design for Industrial Connectivity
This LECHUAN C091 M16 circular socket receptacle addresses the needs of electrical connectors manufacturers and wire harness connector manufacturers focusing on reliable, field-deployable interconnects. Its female, straight solder termination configuration supports efficient PCB front panel mounting, catering primarily to industrial engineers and system integrators working on modular assembly. The product’s compatibility with 2-24 positions ensures adaptability for diverse wiring harness designs, optimizing integration in complex electrical systems requiring secure, dust- and water-tight connections.
Technical Specifications Ensuring Robust Performance
Technically, the LECHUAN C091 incorporates a copper alloy shell with zinc plating, providing both electromagnetic shielding and corrosion resistance critical for prolonged operational integrity. It supports up to 10A/300V rated current and voltage, meeting stringent requirements for PCB to cable interfaces. The IP67 certification guarantees dust ingress protection and water immersion tolerance, enhancing reliability in harsh environments. Its M16 size and shielded design align with established standards in electronic connector manufacturing, emphasizing precise soldered termination and maintaining signal integrity.
Industrial Applications and Integration Value
The product is widely applicable across several industry sectors, such as enclosure wiring for control panels, industrial automation, and outdoor electronics housing. Its front-panel mount facilitates straightforward installation in rugged or sealed enclosures, favored by wire harness connector manufacturers aiming for maintenance-friendly designs. Additionally, the connector’s resilience and configurability benefit prototype development and testing of solder-type interconnects, providing engineers with dependable connectivity solutions in the design and production phases of electronic and electrical systems.
Product Advantages
Structural and Design Advantages
The LECHUAN C091 M16 leverages a compact, modular circular connector design optimized by electronic connector manufacturers for scalable wiring configurations from 2 to 24 positions. The solder termination technique ensures strong mechanical and electrical bonds, reducing failure points under mechanical stress. Its IP67-rated enclosure, combined with a copper alloy shell finished in zinc plating, enhances durability and shielding against electromagnetic interference, meeting industry standards. The front panel mounting arrangement simplifies integration within cable harness assembly systems, enabling efficient manufacturing workflows and standardized interface reliability.
Performance and User-Centric Value
This cable connector excels in delivering consistent high-current performance up to 10A and secure voltage stability at 300V, supporting demanding electrical installations. The IP67 rating certifies its suitability for equipment exposed to dust and moisture, thereby extending the operational lifecycle and reducing maintenance overhead. Usability is enhanced by the straight plug orientation that ensures optimal cable routing and ease of assembly in confined panel spaces. Wire harness connector manufacturers and end-users benefit from the connector’s robust construction and versatile configuration options, enabling flexible deployment in various industrial environments.
Use Scenarios
Use in Industrial Control Panel Assemblies
In industrial panel assembly environments, this M16 circular socket receptacle serves as a vital component for secure front-panel wiring connections. Typically employed by electrical connectors manufacturers supplying solutions for factory automation and control systems, the product ensures high reliability within IP67-rated enclosures that protect against contaminants. Its solder termination and shielded design facilitate low-resistance connections critical for sensitive control signals. Integration within panel wiring harnesses streamlines assembly processes, providing consistent mechanical retention and electrical contact stability under challenging shop floor conditions.
Application in Outdoor Equipment and Harsh Environments
|
Product
|
Orientation:Straight
|
|
Shielding :Shielded
|
|
|
Shell Size :M16
|
|
|
Mounting Type:Panel Mount
|
|
|
Material
|
Shell Material:Copper Alloy
|
|
|
Insulation Material :PA66
|
|
|
Contact Material:Copper Alloy
|
|
|
Shell Finish:Zinc Plating
|
|
Contact Finish:Gold Plating
|
|
|
Number Of Positions:5 Pin
|
|
|
Electrical Characteristic
|
Rated current/Voltage: 10A 300V
|
|
|
Contact Plating :Gold/Au-Plating
|
|
|
Contact Diameter.: 1.5mm
|
|
|
Min Wire Gauge:0.05mm
|
|
Max Wire Gauge:0.5mm
|
|
|
Lower Temperature: - 40℃
|
|
|
Upper Temerature: 100 ℃
|
